Power Guard 1KVA PS Standard Backup Online UPS
Quick Details
- Model: PG 1 KVA ONLINE UPS (S)
- Load Capacity: 1000VA / 900W
- Input Voltage: 200/208/220/230/240 VAC
- Output Voltage: 200/208/220/230/240 VAC
- Back Up Time: Up to 15 Minute, Metal Body
23,000৳
0.0৳
| Main Feature | |
| Capacity | 1000VA |
| Load Capacity | 900W |
| Input Voltage | Nominal Voltage: 200/208/220/230/240VAC Input Voltage Range: 110-280 VAC (Based on Load at 50%) Frequency Range: 46Hz-54Hz / 56Hz-64Hz Phase: Single phase with ground Power Factor: R0.99 @ nominal voltage (100% load) |
| Output Voltage | Output Voltage: 200/208/220/230/240VAC Voltage Regulation: ±1% Frequency Range (Synchronized Range): 46 ~ 54 Hz or 56 ~ 64 Hz Frequency Range (Batt. Mode): 50 Hz or 60 Hz ±0.1% Current Crest Ratio: 3:01 |
| Battery | Battery Type: 12 V / 8.2Ah Numbers: 3 Typical Recharge Time: 4 hours recovery to 90% capacity Charging Current (max.): 1.0A DC Voltage: 36 VDC |
| Alarm | Battery Mode: Sounding every 4 seconds Low Battery: Sounding every second Overload: Sounding twice every second Fault: Continuously sounding |
| Indications | LED Panel: UPS status, Load level, Battery level, Input/Output voltage, and Fault conditions |
| Physical Specification | |
| Dimension | 497x497x365mm |
| Manufacture Warranty | |
| Warranty | 1-Year Battery Warranty Under the following conditions, the warranty would not be provided: • UPS burning due to thunder, abnormal overload, insect entrance and others. • If ambient temperature should not be maintained at 20 to 26 degrees Celsius with proper dehumidification. (24/7) • If the product is placed in a dusty and damp place. • In the absence of Generator connectivity Without proper battery charge, the warranty will be void. • Battery swelling and overcharging due to the wrong system voltage setting of the UPS. |
Description
Power Guard 1KVA PS Standard Backup Online UPS
The Power Guard 1KVA 1000VA 900W Online UPS is a reliable and effective way to guarantee that vital systems have a constant power supply. Capable of supporting loads up to 1000 VA or 900 W, it offers dependable power backup for delicate equipment. It maximizes energy use by operating at high efficiency, delivering 87% in AC mode and 83% in battery mode. It is compatible with a range of power sources thanks to its input voltage range of 110–280 VAC and frequency range of 46 Hz–54 Hz and 56 Hz–64 Hz. With three 12V/8.2Ah batteries, the Power Guard 1000VA Online UPS ensures rapid recovery with a normal recharge period of 4 hours to 90% capacity. The online UPS has LED indicators for monitoring UPS status, load level, battery level, input/output voltage, and fault circumstances, giving comprehensive system status information. The alarm features of the Power Guard 1KVA Online UPS notify users of defects, low battery, overload, and battery mode, enabling prompt resolution of such problems. Its easy interaction with Windows, Linux, and Mac systems is made possible by Smart RS-232 management support, which improves monitoring and control capabilities. The Power Guard 1KVA Online UPS is a great option for protecting vital equipment in a variety of applications because it combines dependability, efficiency, and cutting-edge control features.
Under the following conditions, the warranty would not be provided:
• UPS burning due to thunder, abnormal overload, insect entrance and others.
• If ambient temperature should not be maintained at 20 to 26 degrees Celsius with proper dehumidification. (24/7)
• If the product is placed in a dusty and damp place.
• In the absence of Generator connectivity Without proper battery charge, the warranty will be void.
• Battery swelling and overcharging due to the wrong system voltage setting of the UPS.
