ASRock X370 Killer SLI AMD Motherboard
Quick Details
- Model: X370 Killer SLI
- AMD Socket AM4
- 2 PCIe3.0x16,4PCIe2.0 x1,1 M.2(Key E)
- Chipset-AMD Promontory X370
- Supports DDR4 2933+ (OC)
14,000৳
0.0৳
Basic Information | |
Supported CPU | - Supports AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen Series CPUs (Summit Ridge, Raven Ridge and Pinnacle Ridge) - 12 Power Phase design - Supports 105W Water Cooling (Pinnacle Ridge); Supports 95W Water Cooling (Summit Ridge); Supports 65W Water Cooling (Raven Ridge) |
Chipset | AMD Promontory X370 |
BIOS | 128Mb AMI UEFI Legal BIOS with GUI support - Supports "Plug and Play" - ACPI 5.1 compliance wake up events - Supports jumperfree - SMBIOS 2.3 support - CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V, VDDP, PROM 2.5V, Voltage Multi-adjustment |
Form Factor | ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
Expansion Slots | |
PCI | AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge) - 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4))* AMD 7th A-Series APUs - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE2))* AMD Ryzen series CPUs (Raven Ridge) - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE2))* AMD Athlon series CPUs - 1 x PCI Express 3.0 x16 Slot (single at x4 (PCIE2))* - 4 x PCI Express 2.0 x1 Slots |
M.2 Socket | 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Summit Ridge, Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with A-Series APU and Athlon 2xxGE series APU)* - 1 x M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s)* |
Memory | |
Type | Dual Channel DDR4 Memory Technology |
Slots | 4 x DDR4 DIMM Slots |
Supported Memory | AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 2933+(OC)/2667/2400/2133 ECC & non-ECC, un-buffered memory* - AMD Ryzen series CPUs (Summit Ridge) support DDR4 2933+(OC)/2933(OC)/2667/2400/2133 ECC & non-ECC, un-buffered memory* - AMD Ryzen series CPUs (Raven Ridge) support DDR4 2933/2667/2400/2133 non-ECC, un-buffered memory* - AMD 7th Gen A-Series APUs support DDR4 2400/2133 ECC & non-ECC, un-buffered memory* |
Maximum Memory | Max. capacity of system memory: 64GB |
Graphics | |
Graphics | - Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) - Supports HDCP 1.4 with HDMI Port - Supports Full HD 1080p Blu-ray (BD) playback with HDMI Port |
Max Shared Memory | Shared memory default 2GB. Max Shared memory supports up to 16GB |
Connector & Ports | |
HDMI | HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz |
USB (s) | 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (Supports ESD Protection) |
LAN Port (s) | - Gigabit LAN 10/100/1000 Mb/s - GigaLAN Intel® I211AT - Supports Wake-On-LAN - Supports Lightning/ESD Protection - Supports Energy Efficient Ethernet 802.3az - Supports PXE |
Supported Storage | - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Summit Ridge, Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with A-Series APU and Athlon 2xxGE series APU)* - 1 x M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s) |
Audio | - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec) - Premium Blu-ray Audio support - Supports Surge Protection - Nichicon Fine Gold Series Audio Caps - PCB Isolate Shielding - Individual PCB Layers for R/L Audio Channel |
Internal I/O Ports | - 1 x COM Port Header - 1 x TPM Header - 1 x Power LED and Speaker Header - 1 x AMD Fan LED Header* - 2 x RGB LED Headers* - 1 x CPU Fan Connector (4-pin)** - 1 x CPU Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** - 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) - 1 x Chassis Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector - 1 x AMD LED Fan USB Header - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) - 2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (Supports ESD Protection) |
Warranty Information | |
Manufacturing Warranty | 03 Years |
Description
Asrock X370 Killer SLI ATX Super Alloy AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen Series CPUs supported Dual Channel DDR4 maximum 64GB memory motherboard has the capability of Ultra-Fast 2 PCIe 3.0 x16, 4 PCIe 2.0 x1, 1 M.2 (Key E) Slots interface. Considering the graphics, it will support integrated Intel HD Graphics and up to 16GB shared graphics memory. This exclusive motherboard has the facility of NVIDIA® Quad SLI™, AMD Quad CrossFireX™, 6 SATA3, 1 Ultra M.2, 12 USB 3.1 Gen1, Intel® Gigabit LAN and 7.1 CH HD Audio connectivity.
Purchase Asrock X370 Killer SLI AMD board at lowest price in Star Tech. Shop online for free home delivery.
