ASRock H81M-VG4 R3.0 Super Alloy ATX Motherboard
Special Price:
8,500৳
Regular Price:
0৳
MIT Point:
0
Status:
In Stock
Product ID:
00546
Quick Details
- Model: Asrock H81M-VG4 R3.0
- Supports 4th Generation Intel Processor
- Chipsets: Intel® H81
- Supports Dual Channel DDR3/DDR3L
- Max capacity 16GB
8,500৳
0.0৳
EMI
Price*
Start form 3210৳/month. For Discount
Price
Check here to
view
27 bank emi plans
| Basic Information | |
| Supported CPU | Supports New 4th and 4th Generation Intel® Xeon® / Core™ i7 / i5 / i3 / Pentium® / Celeron® Processors (Socket 1150) Supports Intel® Turbo Boost 2.0 Technology |
| Chipset | Intel® H81 |
| BIOS | 32Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 1.1 Compliant wake up events SMBIOS 2.3.1 support CPU, DRAM Voltage multi-adjustment |
| Form Factor | Micro ATX Form Factor Solid Capacitor for CPU power |
| Expansion Slots | |
| PCI | 1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode) 1 x PCI Express 2.0 x1 Slot |
| M.2 Socket | No |
| Memory | |
| Type | Dual Channel DDR3/DDR3L Memory Technology |
| Slots | 2 x DDR3/DDR3L DIMM Slots |
| Supported Memory | Supports DDR3/DDR3L 1600/1333/1066 non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Maximum Memory | 16GB |
| Graphics | |
| Graphics | Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz |
| Max Shared Memory | 1024MB |
| Connector & Ports | |
| D-Sub (s) | 1 x D-Sub Port |
| USB (s) | 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) |
| LAN Port (s) | PCIE x1 Gigabit LAN 10/100/1000 Mb/s Realtek RTL8111C Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports LAN Cable Detection Supports PXE |
| Supported Storage | 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug |
| Audio | 7.1 CH HD Audio (Realtek ALC887 Audio Codec)* Supports Surge Protection (ASRock Full Spike Protection) |
| Internal I/O Ports | 1 x Chassis Intrusion Header 1 x CPU Fan Connector (4-pin) 1 x Chassis Fan Connector (4-pin) 1 x 24 pin ATX Power Connector 1 x 4 pin 12V Power Connector 1 x Front Panel Audio Connector 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) |
| TPM (Trusted Platform Module ) | 1 x TPM Header |
| Warranty Information | |
| Manufacturing Warranty | 03 years |
Description
Asrock H81M-VG4 R3.0 Super Alloy ATX Motherboard
ASRock H81M-VG4 R3.0 Super Alloy,Supports New 4th Generation Intel® Core™ Processors (Socket 1150).Supports Dual Channel DDR3 1600.1 PCIe 2.0 x16, 1 PCIe 2.0 x1.Graphic Output: D-Sub.7.1 CH HD Audio (Realtek ALC887 Audio Codec).2 SATA3, 2 SATA2.2 USB 3.1 Gen1 (Rear).Supports Full Spike Protection, ASRock Live Update & APP Shop
